MYIR | System-On-Modules (SOMs)

MYC-IMX28X CPU Module

The MYC-IMX28X is a cost-effective, high-performance System-on-Module (SoM) based on the NXP i.MX28 series processors, featuring an ARM926EJ-S core clocked up to 454MHz. It integrates 128MB DDR2 SDRAM, 256MB Nand Flash, and 128KB SPI Flash, with support for extended temperature operation, making it suitable for industrial applications such as smart gateways, HMIs, medical devices, and IoT devices. The module also features onboard Ethernet PHY, CAN, USB ports, and more, providing versatile connectivity options..

  • Detail
  • Special Features
  • Specification

The MYC-IMX28X CPU Module is designed for use in a variety of embedded industrial applications where low power and high connectivity are essential. The module runs on the NXP i.MX28 processor family and integrates a wide range of peripherals, making it ideal for applications such as HMIs, handheld devices, smart gateways, and industrial communication systems. The MYC-IMX28X is highly versatile with support for multiple interfaces, including Ethernet, USB, serial ports, SPI, and more, enabling rapid integration into custom applications. Additionally, the module is ready-to-run with Linux 2.6.35, providing developers with an established operating system and software tools for easy development.

  1. Processor:

    • Freescale i.MX28 processor (i.MX283 or i.MX287)

    • ARM926EJ-S core up to 454MHz

    • On-chip SRAM (128KB), ROM (128KB), and integrated mask-programmable ROM

  2. Memory & Storage:

    • 128MB DDR2 SDRAM

    • 256MB Nand Flash

    • 128KB SPI Flash

  3. Connectivity:

    • Onboard Ethernet PHY

    • 2x USB 2.0

    • Up to 6x Serial ports, including Debug

    • 2x CAN interfaces (only for i.MX287)

  4. Expansion & I/O:

    • 1x I2C, 2x SPI, 8x ADC, 5x PWM

    • 2x 1.27mm pitch 40-pin SMT male connectors for expansion

  5. Temperature & Power:

    • Operating range: -40~85°C (industrial grade)

    • Power supply: 5V

  6. Operating System Support:

    • Linux 2.6.35

  • Processor:

    • Freescale i.MX283 (ARM926EJ-S)

    • Clock Speed: Up to 454MHz

  • Memory:

    • 128MB DDR2 SDRAM

    • 256MB Nand Flash

    • 128KB SPI Flash

  • Connectivity:

    • 1x Ethernet PHY

    • 2x USB 2.0

    • Up to 6x Serial Ports

    • 2x CAN (only for i.MX287)

  • Expansion:

    • 2x 40-pin SMT male connectors

    • I2C, SPI, ADC, PWM

  • Temperature:

    • Operating Range: -40~85°C

  • OS Support:

    • Linux 2.6.35
